Y31180-1/Y31180-2 General Gear Hobbing Machine for Industrial Manufacturing

Y31180-1/Y31180-2 General Gear Hobbing Machine for Industrial Manufacturing

The Y31180-1 and Y31180-2 gear hobbing machines are ideal for batch and single-piece production of cylindrical gears, helical gears, worm gears, and sprockets. With high rigidity, precision, and versatile up/down milling and axial/radial machining, they deliver reliable performance for heavy-duty industrial applications.

Order(MOQ) :
1
Product Origin :
China
Color :
China
Shipping Port :
Shanghai
Lead Time :
30
Weight :
14T/14.5T

Inquire Now

1.Superior Rigidity & Strength: Heavy-duty construction ensures stable cutting performance and long-term reliability.

2.High Machining Accuracy: Precision engineering delivers consistent gear quality for critical applications.

3.Flexible Cutting Modes: Supports both up milling and down milling, with axial and radial feed options.

4.Wide Application Range: Suitable for various gear types including cylindrical, helical, worm, and sprocket gears.

5.User-Friendly Design: Simple adjustment, operation, and maintenance for maximum productivity.

specification

Specification	Unit Model		Y31180-1	Y31180-2
Max workpiece dia	mm	With small pillar	1650	1650
	mm	Without small illar	2000	2000
Max module	Module Steel		12	12
	Module Cast iron		16	16
Max width	mm		450	800
Max dia/length of hob cutter	mm		245/220	245/220
Worktabel dia	mm		950	950
Arbor dia	mm		27/32/40/50	27/32/40/50
Max workpiece weight	T		3	3
Toolhead max angle			±60°	±60°
Main motor	KW		11	11
Spindle taper	Morse		Morse 6	Morse 6
Distance from hob cutter to worktable axes center	mm		200-700	200-1000
Distance from hob cutter to worktable axes center	mm		100-1100	100-1300
Worktabel aperture	mm		200	200
Machine size	mm		426520402400	426520402700
Net weight	T		14	14.5

product introduction

The Y31180-1 and Y31180-2 series represents a robust family of gear hobbing machines built for demanding industrial environments. Designed to handle cylindrical gears, helical gears, worm gears, and sprockets, these machines combine high rigidity with exceptional cutting precision. Whether processing in batches or as single pieces, the Y31180 series delivers stable, accurate, and efficient gear production, with flexible machining options to suit a wide range of applications.

JIANGSU KINGSTON MACHINE TOOLS GROUP CO.,LTD

Jiangsu Kingston Machine Tools Group began making our mark in the metal fabrication world 20 years ago when we established a prominent organization in 1998 marketing, selling, servicing and supporting metal working equipment and material handling products in the International market. Wanting to offer our customers a more flexible and higher quality line of machine tools to meet their most exacting needs we extensively researched and then approached the finest producers of metal fabrication equipment around the globe including the world's largest volume manufacturer of Gear Hobbing, CNC Metal Spinning Machine, Press brakes and Plate rolls etc to build machines to our specifications under the Kingston label. Our machines include Gear Hobbing, CNC Metal Spinning Machine, Hydraulic iron worker machine, press brake, shearing machine, rolling machine, section bender punching machines plasma and laser cutting machines, as well as Lathe machine etc.

Why choose us

Community charging overall solution covers all application

Mature And Stable Technology
With years of experience in manufacturing industrial machine tools and CNC equipment, we adopt mature and stable processes from structural design, core component selection to complete machine assembly. Our machines feature reliable performance, low failure rate and good precision retention, able to meet long-term continuous production demands, making us the preferred partner for customers worldwide.
Support Customized Solutions
We provide exclusive customized solutions according to customers’ workpiece specifications, processing technology, production capacity and on-site conditions, including CNC system, travel, speed, tool changer, fixture and automation upgrading. One machine with one solution to help you improve efficiency, reduce cost and enhance competitiveness.
Complete After-sales Service
We have a professional after-sales and technical team to provide worldwide installation, commissioning, operation training and maintenance guidance. 24-hour online service.Quick response for any equipment problem, timely remote technical support and on-site service if necessary, ensuring uninterrupted production and worry-free use.

Our certification

Authoritative Certifications, Stable and Reliable Quality.

factory show

Professional Production Base, Strength in Precision Manufacturing

automatic cnc gear hobbing machine large gear hobbing machine metal gear hobbing cutting machine y3150 gear hobbing machine

Packing and shipping

Safe & Professional Transportation, On-Time Delivery Guaranteed

Multifunctional machine manufacturer Heavy machinery manufacturer

Q1: What is the difference between Y31180-1 and Y31180-2?

A1: The Y31180-2 offers a larger maximum machining width of 800mm compared to 450mm on the Y31180-1, with heavier construction for more demanding applications.

Q2: What is the maximum workpiece diameter?

A2: With a small pillar, maximum diameters are 1650mm for both models; without a small pillar, Y31180-1 reaches 2000mm and Y31180-2 reaches 2000mm.

Q3: What is the maximum module?

A3: Both machines can handle steel modules up to 12mm and cast iron modules up to 16mm.

Q4: What types of gears can these machines process?

A4: They can process cylindrical gears, helical gears, worm gears, and sprockets.
