YK31125E 4-Axis CNC Gear Hobbing Machine for Large-Diameter Workpieces

The YD3150 is a 4-axis CNC gear hobbing machine designed for high-flexibility gear production. It processes spur gears, helical gears, and spline shafts with maximum workpiece diameter of 500mm and module capacity up to 12mm. The multi-axis coordinated control enables complex gear geometries with superior surface finish

Order(MOQ) :
1
Product Origin :
China
Color :
China
Shipping Port :
Shanghai
Lead Time :
30
Weight :
18000KG

Inquire Now

1.Large Diameter Capacity: Handles workpieces up to 1250mm maximum diameter.

2.16mm Module Capability: Supports steel modules to 16mm for robust gear production.

3.Thermal Stability Design: Integrated fluid circulation maintains temperature stability during long operations.

4.High-Precision Worktable: Premium worm gear drive ensures accurate indexing.

5.Backlash-Free Feed System: Pretension ball screws on linear slides minimize positioning error.

specification

Description	Specifications
Max. workpiece dia.	1250mm
Max. module	10mm
Hob head slide travel	400mm
Max. hob head swivel	±45rad
Max. hob dimensions （dia. × length）	200×240mm
Max. axial travel of the hob	200mm
Center distance between hob and worktable	45~405mm
Distance between hob center and worktable surface	280~680mm
Distance between workstay center and worktable surface	390~890mm
Max.Tooth width	200 mm
Table hole dia	120 mm
Spindle speed	80~500r/min
Max. worktable speed	50r/min
Max. radial feed speed (X-axis)	2600 mm/min
Max. tangential feed speed (Y-axis)	2000 mm/min
Axial feed speed（Z-axis）	2600 mm/min
Max. hob head rotary speed	5rad/s
Main motor power	18.5KW
Total power	50Kw/50Hz
Net weight	17000Kg(6 AXIS )/15000KG(4 AXIS)
Overall dimensions	42×39×37cm

product introduction

The YK31125E is a 4-axis CNC gear hobbing machine built for large-diameter gear production. With a maximum workpiece diameter of 1250mm and module capacity up to 16mm for steel, this machine handles substantial gear blanks with precision and efficiency. The cast-iron machine bed features maximum static and dynamic rigidity with integrated fluid circulation for thermal stability, ensuring dimensional accuracy even during extended cutting cycles. The worktable is driven by high-quality, high-precision worm and worm wheel gearing, while linear slides with backlash-free pretension ball screws deliver smooth, accurate feed motion
